In vitro Antifungal Activity of Some Indigenous Medicinal Plant Extracts against Five Isolates of Aspergillus fumigatus

*Corresponding Author:

Eman F. Sharaf Department of Botany and Microbiology, Faculty of Science, Cairo University, Giza 12511, Egypt E-mail: emanfsharaf@yahoo.com

This is an open access article distributed under the terms of the Creative Commons Attribution-NonCommercial-ShareAlike 3.0 License, which allows others to remix, tweak, and build upon the work non-commercially, as long as the author is credited and the new creations are licensed under the identical terms

Abstract

There is a constant exposure of humans to Aspergillus mold fungus and 95 % of the pathogenic species. It is important to study drugs with new efficacy against infections because of increased prevalence of infections resistant to antibiotics. The present study aims to assess the antifungal activity of aqueous and ethanol plant extracts (cinnamon, garlic, ginger and guava) against five isolates of the opportunistic mold Aspergillus fumigatus. The results showed that effect of ethanol and aqueous extracts of cinnamon was same on all the five isolates of Aspergillus fumigatus. The recorded diameters of inhibition zone for isolates 1, 2, 3, 4 and 5 exerted by the cinnamon ethanol extracts were 41, 46, 40, 45 and 46 mm respectively. Moreover, ginger was excluded in next experiments because all the isolates showed resistance against the aqueous and ethanol extract of ginger, except for isolate 5. Minimum inhibitory concentration was 2 mg/ ml ethanol extract of garlic and cinnamon whereas that of aqueous extract of garlic and cinnamon was 40 mg/ml and 10 mg/ml, respectively. The study concluded that ethanol extract of cinnamon can be used as antimycotic agent against Aspergillus fumigatus to treat diseases but it is urged to detect the sensitivity of fungal isolate to the extract before using as different responses are provided by isolates in a wide range of extracts.

Keywords

Antifungal activity, Aspergillus fumigatus, extracts, aspergillosis, toxicogenic

Aspergillus fumigatus (A. fumigatus) is a known fungus belonging to genus Aspergillus. This fungus results in the development of certain disease among the immune compromised individuals and cause allergic reactions[1]. The infection caused by A. fumigatus is called aspergillosis that is a life threatening fungal infection[2]. Thousands of minute grey-green conidia are produced in fungal colonies from the conidiophores that may become airborne[3]. These spores are present in the atmosphere and can be inhaled. There is increased occurrence of A. fumigatus among the poultry flocks causing mild or even severe forms of diseases, which results in greater economic losses. The severity of infection outcome depends on the hygienic conditions and immune system of different animals[4]. The concentration of fungal spores and bacteria is likely to increase in the atmosphere as a result of warm temperature, degraded litters, poor ventilation, long-term feed storage and excessive ammonia and moisture[5,6].

The broad spectrum of diseases caused by the members of genus Aspergillus are encompassed as aspergillosis, which develop as a result of contaminated intra-hospital environments, direct inoculation through surgical tools, inhalation of toxic compounds, air conditioners and mechanical ventilation[7,8]. It has been shown that the antifungal drugs that are used currently are only partially effective in treating the infection[9]. There is increase in the appearance of Aspergillus strains in the hospital settings[10,11]. There is need to identify new targets and develop new antifungal agents as therapeutic alternatives that would be effective antifungal agents[12].

The medicinal plants containing active cheap constituents are economic and useful in treating much human-related disease[13,14]. The oil of four Iranian herbs including, Thymus daenensis var daenensis Celak, Zataria multiflora Boiss, Thymbra spicata var. spicata L. and Bunium persicum (Boiss) for antifungal activity against A. niger, A. fumigatus, A. flavus and A. parasiticus was investigated by Pirbalouti et al.[15]. The results showed that the oils from Thymus daenensis and Thymbra spicata are likely to be used as natural antifungals for preserving food and health of humans. Another study conducted by Mann et al.[16] showed that aqueous root extracts of Anogeissus leiocarpus and Terminalia avicennioides inhibit the growth of the all tested organisms. Moreover, the minimum fungicidal concentration (MFC) ranged between 0.04 and 0.08 µg/ml; while, minimum inhibitory concentration (MIC) of the extracts ranged between 0.03 and 0.07 µg/ml. A large growth inhibition zone was developed by Carmo et al.[17] as he reported strong antifungal activity and growth inhibition for Cinnamomum zeylanicum (C. zeylanicum) on the growth and morphogenesis of some potentially pathogenic Aspergillus species. the decreased conidiation, loss of pigmentation, cytoplasm leakage and disrupted cell structure are the major morphological changes observed as a result of degradation of the fungal wall. Therefore, Carmo et al.[17] concluded that protection against growth of Aspergillus species could be provided by C. zeylanicum essential oil as it works as potential antifungal compound.

The health of individuals is significantly affected as a result of increased prevalence of drug resistance among the infectious agents. Doust et al.[18] demonstrated the incidence and spread of drug resistance among various agents including fungi. Nowadays, conducting research on drugs with new efficacy against infections is important because of increased in the infections resistant to antibiotics[19,20]. Humans are constantly exposed to Aspergillus mold fungus and 95 % of the pathogenic species include three species of Aspergillus including A. fumigatus, A. flavus and A. niger[21]. These species may cause local infections in different body organs like lungs and sinuses, no matter how healthy an individual is[22]. Moreover, this infection can result in severe consequences among individuals with deficient immune systems. None of the previous studies have elucidated effect of the most potent natural antifungal plant extract on some growth criteria of A. fumigatus. Therefore, the present study aims to assess the antifungal activity of ethanol plant extracts against the opportunistic mold A. fumigatus.

Materials and Methods

The fresh plant samples including ginger, garlic, cinnamon sticks and guava leaves used in this study were purchased from Al-Madinah local market. Five isolates of A. fumigatus were obtained from the Microbiological Laboratory of the Department of Biology, Taibah University. A. fumigatus isolates were confirmed by Raper & Fennell[23] and El-Shafie[24] to belong to genus Aspergillus.

Culture medium:

The culture medium that is Czapek Dox’s agar medium used in this study comprises of following constituents: 20 g/L sucrose; 3 g/L sodium nitrate (NaNO₃); 1 g/L potassium dihydrogen phosphate (KH₂PO₄); 0.5 g/L magnesium sulfate heptahydrate (MgSO₄.7H₂O); 0.5 g/L potassium chloride (KCl); 0.05 g/L ferrous sulfate pentahydrate (FeSO₄.5H₂O); 20 g/L agar; 1 L distilled water.

Preparing plant extracts:

The fresh plant samples were washed, sterilized, cut and dried at room temperature. The dried form of plant extracts was converted into fine dry powder in electric grinder. The hot aqueous extract was prepared by soaking 20 g of plant powder in 100 ml distilled water and the mixture was left at 60° in water bath, for 30 min. Whereas, ethanol extract was prepared according to Varghese[25] method by adding 20 g of plant powder to 100 ml of 95 % ethanol and left overnight then filtered. The produced filtrate was of 20 % (w/v) concentration (200 mg/mL). The suspension was centrifuged at 5000 rpm for 10 min and filtered through a Whatman No .1 filter paper. The supernatant fluid was allowed to evaporate under pressure through the rotary evaporator apparatus. The concentrated organic solvent extracts were dissolved in 10 % dimethyl sulfoxide (DMSO) and kept at -20°[26].

Antifungal activity:

The agar well diffusion method proposed by Hadacek et al.[27] was used to carry out the inhibitory activity of plant extracts. The plates (triplicates) were seeded with 1 ml of fungal homogenous spore suspension of 5 d old culture and after inoculum absorption wells were made using sterile cork borer (9 mm diameter) then 100 μl of the extracts were introduced into each well. The plates were left for 30 min for better absorption. Later, the plates were incubated at 28º for 48 h. Control was conducted using either sterile distilled water or DMSO. Measurement was obtained for the diameter of the produced inhibition zones after subtraction of control value and taken as a criterion for the inhibitory activity.

Extraction using different organic solvents:

Different solvents were prepared[25] and tested to obtain the best one for extraction, because of increased higher antifungal activity of aqueous and ethanolic extract of the tested plants against isolate 2 of A. fumigatus. Antimicrobial activity of the prepared plant extracts was tested against isolate 2 of A. fumigatus. Control was conducted with each solvent separately and means were calculated after subtraction of control value (DMSO). Aqueous and ethanol cinnamon and garlic extracts were chosen for the next experiments as they helped in achieving the most potent antimicrobial activity.

Determining minimum inhibitory concentration (MIC):

MIC was determined using different concentrations of either ethanol extract or hot water extract of both cinnamon and garlic as explained by Gayoso et al.[28].

Data analysis:

The data was added and analyzed using Statistical package of social sciences (SPSS). Analysis of variance (ANOVA) was used to determine the significant differences.

Results and Discussion

Table 1 shows the antifungal activities of four plant extracts selected in the present study. Significant variation of inhibition was exerted by the plant extracts on the growth of five isolates of A. fumigatus (p≤0.05). Isolates 1 and 2 were affected by the ethanol extract of guava leaves, with 36 mm and 30 mm of inhibition zone diameters, respectively. However, isolate 1 was affected by hot water extract with inhibition zone diameter of 40 mm. The effect of ethanol and aqueous extracts of cinnamon was same on all the five isolates of A. fumigatus.

Table 1: Antifungal Activity of The Tested Plant Extracts Against A. fumigatus Isolates Expressed as Diameter of Inhibition Zone (mm)

For isolates 1 to 5, the recorded diameters of inhibition zone exerted by the cinnamon ethanol extract were 41, 46, 40, 45 and 46 mm respectively. As compared to the ethanol extract of cinnamon, the aqueous extract of cinnamon was less effective and the diameter of inhibition zone of isolates 1, 2, 3 and 4 were 20, 23, 21 and 19 mm respectively. There was no impact of aqueous extract of cinnamon on isolate 5. Inhibition effect against isolates 2, 3 and 5 was shown in the presence of aqueous extract of garlic; however, other isolates showed resistance against the aqueous extract of garlic. On the contrary, the ethanol extract of garlic was able to exert its effects in isolates 1 and 2 (inhibition diameter was 20 and 44 mm, respectively). In the similar context, ginger was excluded in next experiments because all the isolates showed resistance against the aqueous and ethanol extract of ginger, except for isolate 5. Isolate 5 was weakly affected by aqueous extract of ginger with 15 mm diameter of inhibition zone.

Different solvents were tested for selecting the most effective one because the ethanol extract of all the tested plant extracts was inhibitory to the most sensitive isolate 2 (Table 2), except for ginger. Therefore, the best solvent for extraction was ethanol, as it exerted significant inhibitory activity (p≤0.05), as compared to methanol, ethyl acetate and chloroform. Moreover, there was significant effectiveness of ethanol extract of garlic and cinnamon, as compared to the guava extracts. However, there was no impact of chloroform extract of guava leaves on isolate 2 of A. fumigatus.

Table 2: Antifungal Activity of The Tested Plants Against Isolate 2 of A. fumigatus after Extraction With Different Solvents

The results demonstrate that cinnamon and garlic different solvent extracts showed the prominent antifungal activity against isolate 2 of A. fumigatus fig. 1A-1D. Therefore, MIC against isolate 2 of A. fumigatus was determined using these two plant extracts. Table 3 has illustrated MIC for garlic and cinnamon against isolate 2 of A. fumigatus, after incubation of 48 h. The table shows that MIC of 2 mg/ml ethanol extract of garlic and cinnamon with inhibition zones of 17 and 20 mm respectively. Moreover, MIC of aqueous extract of garlic was 40 mg/ml with 18 mm of inhibition diameter; whereas, MIC of aqueous extract of cinnamon was 10 mg/ml with 11 mm of inhibition diameter.

Figure 1: Inhibitory activity of the different solvent extracts of cinnamon and garlic against A. fumigatus I₂ (A) ethanol; (B) methanol; (C) chloroform; (D) ethylacetate

Table 3: Mic Of Garlic and Cinnamon Extracts Against Isolate 2 of A. fumigatus

Majority of the dreadful diseases whether animal or plant are controlled using economically essential medicinal plants. The present study has evaluated the inhibitory effect of alcoholic and aqueous extracts of ginger, garlic, cinnamon and guava against the isolates of A. fumigatus. There was a difference in the degrees of inhibition among the four plant extracts; however, isolates 1 and 2 were affected by ethanol extract of guava leaves. Resistance was shown by all the isolates against aqueous and ethanol extract of ginger. Antifungal activity is exhibited by all the prepared water and ethanol cinnamon extracts against the isolates of A. fumigatus. This finding stated that inhibitory effect of cinnamon ethanol extract for the isolates was in line with the study conducted by Rodriguez et al.[29]. The results demonstrated that antimicrobial activity against Rhizopus stolonifer and Fusarium oxysporum (F. oxysporum) f. sp. lycopersici (Sacc) was presented in the presence of various aqueous and alcohol extracts/ essential oil distillates.

Previous studies have also exhibited antimicrobial activity of aqueous cinnamon extract for F. culmorum Sacc, F. oxysporum, A. niger, Alternaria alternate, along with some hydrolytic enzymes[30-31]. These hydrolytic enzymes include pectin, protease, lyase and Beta-glucosidase. Similarly, the activity of Syzygium, Cymbopogon, and Cinnamomum species against Trichophyton rubrum (T. rubrum) and A. fumigatus was reported by Khan and Ahmad[32]. Similar to the present study, cinnamon was proved to be effective against some species of toxicogenic fungi and respiratory tract pathogens.

The results of present study showed that antifungal activity against A. fumigatus isolates was exhibited by aqueous and ethanol garlic extracts. These results were consistent with the study conducted by Natheer[33]. The study exhibited strong inhibitory effect by diethyl ether extract of cinnamon for the tested bacteria and Candida albicans (C. albicans). Nevertheless, the antifungal activities of the ethanol extract of Zingiber officinale, mycelial dry weight and Annona muricata, Alchornea cordifolia, Garcinia cola and Allium sativum against the mycelial elongation of Rhizopus stolonifer, Botrydiplodia theobromae, A. niger, F. solani, and F. oxysporum was reported by Amienyo and Ataga[34].

Similar to the results presented in the present study, Dhiman et al.[35] showed that inhibition in growth of Escherichia coli, Pseudomonas aeruginosa, Staphylococcus aureus, A. niger and C. albicans was due to the effect of methanolic extract of Psidium guajava (P. guajava) using paper disc diffusion method. However, Rathish and Sumitra[36] had stated inactivity of extracts of P. guajava against A. flavus, A. niger and A. candidus.

The present study has tested different solvents for selecting the most effective one, along with the ethanolic extract and presented high antifungal activity of cinnamon, garlic and guava ethanolic extract against isolate 2 of A. fumigatus. The ethanol extracts were considered to be powerful inhibitor, as compared to the extracts of methanol and chloroform. These results were similar to a previous study conducted by Senhaji et al.[37] showing active antimicrobial potential of ethanolic and hexanic extracts of cinnamon, as compared to other solvent extracts. On the contrary, antimicrobial activity was shown by methanol extract of C. zeylanicum towards microorganisms[38].

The morphological changes taking place within the endomembrane   structures   and   cell   membrane   of A. fumigatus and T. rubrum were observed by Khan and Ahmad[32] using electron light microscope after being treated with cinnamon oil. Cinnamon and other oils exhibited inhibitory effects against the synthesis of cell membrane and cell wall. The cell membrane along with other endomembrane structures of the cell was the primary target of oils; however, synthesis of cell wall was required due to disruption of cell membrane and other associated enzymes. The growth of microorganism is likely to be inhibited by cinnamaldehyde, which is a highly electronegative compound interfering with the biological processes that involve electron transfer and reaction with nitrogen containing compounds.

This study has determined MIC based on the preparation procedure used by Gayoso et al.[28] undertaking different concentrations of either ethanol extract or hot water extract of both garlic and cinnamon. These concentrations include 1, 2, 6, 10, 20 and 40 mg/ml, the plates were incubated at 28° and after measuring the diameters of inhibition zone and the inhibitory activity was followed. Inhibition zone equal to 10 mm or more was considered for the MIC, which shows the lowest concentration[39,40].

The present study has investigated the antifungal activity of ethanol and aqueous extract against the opportunistic fungus A. fumigatus. The results showed inhibitory effect of ethanol extract of cinnamon, as compared to ginger, garlic and guava extracts. Therefore, it has been concluded that ethanol extracts of cinnamon can be used as antimycotic agent against A. fumigatus to treat diseases, rather than using chemical drugs having side effects. The use of natural products for treating various diseases is considered to be cheap, safe and ecofriendly source that reduce the complications and hazards of using chemical drugs. The study has suggested determining the sensitivity of fungal isolate to cinnamon extract before using it as different responses are provided by isolates in a wide range of extracts.

Acknowledgements:

The authors are very thankful to all the associated personnel in any reference that contributed in/for the purpose of this research.

Conflict of interests:

The authors declared no conflicts of interest.
